Dahua

PFS3106-4ET-60-V2

Ürün Kodu : PFS3106-4ET-60-V2
4Port PoE Switch (4FE PoE + 1GE + 1GE SFP, Toplam 60W PoE )
Liste Fiyatı :
135,00 USD
Size Özel Fiyatı :
135,00 USD +KDV
Stok Adedi :
  • Ürün Özellikleri
  • Ödeme Seçenekleri
  • Tavsiye Et
  • Resimler
  • Döküman

  • PFS3106-4ET-60

    4-Port PoE Switch (Unmanaged)

    > Layer two Hardened PoE switch
    > Supports PoE power management
    > MAC auto learning and aging, MAC address capacity is 8K
    > Conforms to IEEE802.3af and IEEE802.3at power supply standard. Port 1 supports Hi-PoE 60W power supply
    > Supports IEEE802.3, IEEE802.3u, IEEE802.3ab/z and IEEE802.3X standards
    > Wide working temperature design: -30°C~ 65°C
    > Supports dual power backup


    Technical Specification

    Model

    DH-PFS3106-4ET-60

    Ethernet Port

    1*100/1000 Base-X

    1*10/100/1000 Base-T

    4*10/100 Base-T (PoE power supply)

    PoE Power Consumption

    Port1≤60W, Port2-4≤30W, Total≤60W

    PoE PIN Assignment

    1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

    PoE Power Management

    Support

    PoE Protocol

    IEEE802.3af (PoE), IEEE802.3at (PoE+), Hi-PoE

    Switching Capacity

    6.8G

    Packet Forwarding Rate

    3.57Mpps

    Packet Buffer Memory

    1Mb

    MAC Table Size

    8K

    Flow Control

    Enable by default

    Application Humidity

    5%~95%

    Power

    DC 48~57V power adapter

    Lightning Protection

    Common Mode 6KV

    Differential Mode 4KV

    ESD Protection

    Air Discharge 15KV

    Contact Discharge 8KV

    Working Temperature

    -30°C~65°C

    Weight

    440g

    Dimension(W×D×H)

    150mm×108mm×30mm
