MNVR4104
4 Channels POE 1 HDD Mobile Video Recorder
> Support 4 channels POE IP cameras input
> Support H.265/smart H.265 video compression
> Support 4 channels 4MP realtime recording
> VGA, TV, HDMI simultaneous video output
> Support 1 HDD, 3 USB2.0
> Aviation connectors adopted
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
System
Main Processor
Embedded microprocessor
Operating System
Embedded LINUX
Video and audio
IP Camera Input
4 channels
Two-way talk
1 channel Input, 1 channel Output
Display
Interface
1VGA, 2TV,1 HDMI
Resolution
800×600
Display Split
1/4
Privacy Masking
4 rectangular zones (each camera)
OSD
Channel name, time, GPS, license No.
Recording
Video Compression
H.265/smart H.265 /H.264/smart H.264
Audio Compression
G.711A/G.711U/PCM
Resolution
4 ch@4MP realtime recording
Record Mode
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer & Screen tips
Video Detection
Motion Detection, MD Zones:396(PAL:22×18,NTSC:22×15), Video Loss & Tampering
Alarm input
9 channels,Alarm1–8 are local alarm input, Alarm 9 is pulse input.
Alarm Output
2 channels,1 relay out, 1 Controllable 12V out
Playback and Backup
Playback
1 channel
Search Mode
Time/Date, Alarm, Motion Detection & Exact search (accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode
USB Device/Network
Storage
Internal HDD
1 HDD
SD card
1 SD card, Up to 256 GB
Network
Ethernet
RJ-45 Port (10/100Mbps)
Wireless Network
Built-in 3G/4G/Wi-Fi module(optional)
GPS
Built-in high accurate GPS module(optional)
Network Function
TCP/IP, UDP, DHCP, DDNS, FTP, Email, Alarm Server
Max. User Access
128 users
Smart Phone
iPhone, iPad, Android
Auxiliary Interface
USB
3 USB 2.0
RS232
3 Ports
RS485
2 Ports
Heater
Optional
Electrical
Power Supply
DC 6V~36V
Power Consumption
<10.2W (Without HDD)
Environmental
Operating Temperature
-30°C (with heater)~ +70°C (-22°F ~ +158°F)
Operating Humidity
10 ~ 90% RH
Construction
Dimensions
180mm×190mm×50mm (7.0" x 8.7" x 2.0")
Net Weight(without HDD)
1.92Kg(4.23 lb)
Gross Weight
2.93Kg (6.46 lb)
Certifications
CE
FCC
EN50155
ISO7637-2
ISO16750
BIS
E-mark
EN45545-2
-
