DHI-ITC413-PW4D-IZ1

Name: DHI-ITC413-PW4D-IZ1
Brand: Dahua
SKU: T1537
Availability: OutOfStock

Ürün Kodu : DHI-ITC413-PW4D-IZ1

Dahua Erişim ANPR Kamerası

Meta verilerin 7/24 sürekli olarak çıkarılmasını destekleyen yüksek performanslı CMOS görüntü sensörü ve işlemci.
Akıllı derin öğrenme algoritmalarını benimser ve lisanssız araçların, araçların türü, markası ve renginin tanınmasını destekler.
Dahili sinyal portu, veri portu, iletişim portu ve uzaktan kumandalar, giriş ve çıkış bariyerleri gibi harici cihazların kontrolüne yardımcı olur.
İzinsiz giriş ve başıboş dolaşma tespitini destekler ve çevre olayları meydana geldiğinde hedefleri aktif olarak caydırmak için ışıklı ve sesli alarmları tetikler.
Özel sesler de içe aktarılabilir ve düzenlenebilir.IP67 ve IK10 sınıfı.

Ürün Özellikleri
Tavsiye Et
Resimler
Döküman

Image Sensor																		1/1.8" CMOS
Image Resolution																		2688 (H) × 1520 (V)
Electronic Shutter Speed																		Auto/Manual 1/25 s–1/10,000 s
Max. Detection Speed																		80 km/h
Min. Illumination																		0.001 lux@F1.4 (Color, 30 IRE); 0.0002 lux@F1.4 (B/W, 30 IRE); 0 lux (Illuminator on)
ROM																		4 GB
RAM																		1 GB
S/N Ratio																		＞56 dB
Scanning System																		progressive scanning
Focal Length																		2.7 mm–12 mm
Field of View																		H: 92°–46.1°; V: 49°–26.0°; D: 109°–52.8°
Focus Control																		Auto, area focus, manual
Number of Lens																		1
Lens Type																		Motorized vari-focal
Max. Aperture																		1.4
Iris Control																		DC-Iris
DORI Distance																		W: D: 60.4 m; O: 24.2 m; R: 12.1 m; I: 6.0 m (D: 198.16 ft; O: 79.40 ft; R: 39.70 ft; I: 19.68 ft) T: D: 128.7 m; O: 51.5 m; R: 25.7 m; I: 12.9 m (D: 422.24 ft; O: 168.96 ft; R: 84.32 ft; I: 42.32 ft)
Illuminator Number																		4(IR light)
Illuminator On/Off Control																		Auto, manual
Illumination Distance																		ANPR: 10 m (32.81 ft) Video monitoring: 30 m (98.43 ft)
Smart Illumination																		According to the brightness of the environment, the camera automatically adjusts the intensity of its light to reveal the details of moving targets. Devices with warm light can automatically adjust the light intensity according to the time.
Infrared Wavelength																		850 nm
Video Resolution																		Main stream: 4M (2688 × 1520)/1080p (1920 × 1080)/720p (1280 × 720) Sub stream: 720p (1280 × 720)/960H (960 × 576, 960 × 480)/D1 (704 × 576, 704 × 480)/CIF (352 × 288, 352 × 240)
Video Frame Rate																		PAL: Main stream (2688 × 1520@25 fps, 1920 × 1080@25 fps, 1280 × 720@25 fps), sub stream (1280 × 720@25 fps, 960 × 576@25 fps, 704 × 576@25 fps，352 × 288@25 fps); NTSC: Main stream (2688 × 1520@30 fps, 1920 × 1080@30 fps, 1280 × 720@30 fps), sub stream (1280 × 720@30 fps, 960 × 480@30 fps, 704 × 408@30 fps, 352 × 240@30 fps)
Video Compression																		H.265;H.264B;H.264M;H.264H;MJPEG;H.264M by default
Video Bit Rate																		H.264B: 2,179 kbps–13,074 kbps H.264M: 2,179 kbps–13,074 kbps H.264H: 2,179 kbps–13,074 kbps H.265: 2,179 kbps–13,074 kbps MJPEG: 6,537 kbps–39,223 kbps
Scene Self-adaptation (SSA)																		Yes
Gain Control																		Manual; Auto
Noise Reduction																		3D NR
Motion Detection																		Yes
Region of Interest (RoI)																		Yes, 3
Image Tampering Prevention																		Yes. Watermarks can be added to videos and images. The watermark can also be verified.
Bit Rate Control																		VBR;CBR
Storage																		Bult-in TF card port. Supports Kingston 16 G, 32 G, 128 G, 256 G; Dahua card 16 G, 32 G, 128 G, 256 G; SanDisk 16 G, 32 G, 128 G, 256 G
Restricted List/Trusted List																		Allowlist: 110,000 Blocklist: 110,000
IVS																		Intrusion detection, loitering detection, up to 4 areas can be set.
Basic Event																		Alarms for events of defocus, no storage card, storage card no space, storage card error, network disconnection, IP conflict, and illegal access.
Sound and Light Alarm																		Yes, blue & red indicator, and supports broadcasting custom audio.
Alarm Linkage																		Upload to FTP/Memory card, notify monitoring center, send e-mail, trigger alert output, snapshot and active deterrence
Capture Distance																		3 m–8 m (9.84 ft–26.25 ft)
Detected Width																		3 m–4 m (9.84 ft–13.12 ft)
Network Protocol																		HTTP; Https; 802.1x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; IPv4/v6;NTP; SFTP;DDNS; SNMP; PPPoE
API																		Yes
SDK																		Yes
Interoperability																		ONVIF (Profile S/Profile T); CGI; ITSAPI; P2P
Management Software																		DSS Pro; DSS Express; Cybercity; Smart PSS
Security																		Username and password; MAC address; HTTPS; IEEE 802.1x; network access control
Browser																		Plug in: IE 9, 10, 11. Chrome 52 and earlier versions Firefox 42 and earlier versions No plug in: Chrome 92 and later versions
Image Encoding Format																		JPEG
Image Setting																		Brightness; contrast; saturation; gamma; sharpness; gain; white balance
Day/Night																		IR filter, support three modes: color/B/W/auto
WDR																		140 dB
HLC																		Yes
BLC																		Yes
White Balance																		Auto;Manual;Regional Custom;Outdoor;Natural;Street Lamp
Digital Detail Enhancement (DDE)																		Yes
OSD Overlay																		Supports overlay of time; address (position of channel), lane (number/direction), plate (number and color), vehicle (speed, color, type)
Audio Port																		Yes
Built-in MIC																		Yes; Pick-up distance: 3 m (9.84 ft), Sampling Rate: 48 k.
Built-in Speaker																		Yes; Power: 2 W
Audio Output																		1 channel (RCA port)
Network Port																		RJ-45 (10/100/1000 self-adaptive Ethernet Port)
Alarm Input																		2, optocoupler input (wet node on-off value: 5 V)
Alarm Output																		2, relay output (2A 30 VDC/0.5A 125 VAC), which can connect to devices such as barriers
RS-485																		2 (half duplex, Transparent, DHRS, Push Data through Serial Port)
Reset Button																		Yes
Wiegand																		1 Channel, SHA-1 26 bit
Maximum Number of Passed Vehicles																		10000
Max. Number of Connections																		10
AI Recognition																		Recognizes vehicle types, vehicle signs, vehicle color, vehicle plate, plate, vehicle without plate.
Video Metadata																		Displays the intelligent frame, plate and vehicle paths.
Vehicle Brand																		Recognizes 147 vehicle logos.
Vehicle Color																		Recognizes 12 colors: Grey, black, white, silver, blue, green, purple, red, orange, pink, brown, and yellow.
Vehicle Type Recognition																		Recognizes 10 vehicle types: Large Bus, Heavy Truck, Medium Truck, Sedan, Van, Light Truck, Medium Bus, SUV, MPV, Pickup
Capture Rate																		In the recommended installation and lighting condition, the vehicle capture rate ≥ 99%
Recognition Rate																		In the recommended installation and lighting condition, the recognition rate for positive and departing vehicles≥ 96%; the recognition rate for European vehicle plates ≥ 98%
Remote control																		Yes
Communication Band																		868 MHz
Remote Control Distance																		15 m (49.21 ft) (In an open, undisturbed environment)
Power Supply																		12 VDC, 2 A and PoE: 802.3at, Type 2, Class 4, (44 V– 57 V), 0.455 A–0.351 A, max.20 W
Power Consumption																		Power consumption in different conditions: No lighting ＜ 6 W Lighting ＜12 W Speaker and Red/Blue Light Warning on ＜ 17 W
Protection																		IP67;IK10
Material																		Aluminum alloy body + Plastic
Product Dimensions																		395.0 mm × 120.8 mm × 127.8 mm (15.55" × 4.76" × 5.03") (L × W × H)
Packaging Dimensions																		447.0 mm × 240.0 mm × 233.0 mm (17.60" × 9.45" × 9.17")
Net Weight																		2.3 kg (5.07 lb)
Gross Weight																		3.2 kg (7.05 lb)
Storage Humidity																		–40 °C to +70 °C (–40 °F to +158 °F)
Storage Temperature																		≤ 95% (non-condensing)
Operating Temperature																		–30 °C to +65 °C (–22 °F to +149 °F)
Operating Humidity																		10%–90% (non-condensing)
Certifications																		CE-EMC; CE-LVD; CE-RED; FCC
Micro SD Card (Max.)																		TF Card, 1 × 256 GB
